- 1 x Brocade ICX 7250-24P 24x 1GbE PoE+ RJ45 + 2x 1/10Gb SFP+ +6x 1Gb SFP Port Switch
- Switching capacity (data rate, full duplex): 208 Gbps
- Forwarding capacity (data rate, full duplex): 154 Mpps
- Fixed ports: 10/100/1000 Mbps RJ45: 24
- Fixed ports: 1/10 Gbps SFP+ (10 GbE SPF+ optional upgrade license): 8
- Maximum PoE Class 3 ports (internal AC power supply only): 24
- Maximum PoE+ ports (internal AC power supply only): 12
- Maximum PoE+ ports (with external power supply): 24
- Advanced IPv4/v6 L3 routing (RIP, OSPF): with license
- Aggregated stacking bandwidth: 480 Gbps
- Stacking density (maximum switches in a stack): 12
- Maximum stacking distance (distance between stacked switches): 10 km
- Power inlet (AC): C14
- Input voltage / frequency: AC: 100 to 240 VAC @ 50 to 60 Hz
- Power supply rated maximum (AC): 525 W
- PoE power budget (AC) (internal AC power supply only): 370 W
- Switch power draw (25°C):
- Idle (no PoE load): 50 W
- 10% traffic (full PoE load): 63 W
- 100% traffic (full PoE load): 73 W
- Airflow: side-to-back
- Switch heat dissipation (25°C):
- Idle (no PoE load): 170.6 BTU/hr
- 10% traffic (full PoE load): 214.9 BTU/hr
- 100% traffic (full PoE load): 249.08 BTU/hr
- Weight: 4.73 kg
- Dimensions: 440 mm (17.323 in.) W×280 mm (11.02 in.) D×43.7 mm (1.720 in.) H — 1U
- Acoustics (25°C, ISO 7779): 44.7 dBA
- MTBF (25°C): 429,209 hours
- Temperature:
- Operating temperature: −5°C to 50°C/23°F to 122°F
- Storage temperature: −25°C to 70°C/−13°F to 158°F
- Humidity:
- Operating relative humidity: 5% to 95% at 50°C, non-condensing
- Non-operating relative humidity: 0% to 95% at 70°C, non-condensing
- Altitude:
- Operating altitude: 10,000 ft. (3,000 m) maximum
- Storage altitude: 39,000 ft. (12,000 m) maximum
- Connector options:
- 10/100/1000 ports: RJ-45
- 1 Gbps SFP ports (Brocade ICX 7250-24G only)
- 1/10 Gbps SFP+ ports (not available on Brocade ICX 7250-24G)
- Out-of-band Ethernet management: 10/100/1000 Mbps RJ-45
- Console management: Mini-USB serial port (Mini-B plug)
- File transfer: USB port (Standard-A plug)
- Maximum MAC addresses: 16,000
- Maximum VLANs: 4,095
- Maximum STP (spanning trees): 254
- Maximum routes (in hardware): 12,000
- Trunking: 16
- Maximum jumbo frame size: 9,216 bytes
- Average latency: 1.5 µs
- QoS priority queues: 8 per port
ICX7250-24PSwitch# show version
Copyright (c) 1996-2015 BrocadeCommunications Systems, Inc. All rights reserved.
UNIT 1: compiled on Apr 7 2016 at 07:24:36 labeled as SPS08040a
(22642415 bytes) from Primary primary
SW: Version 08.0.40aT211
Compressed Boot-Monitor Image size =786944, Version:10.1.06T215 (spz10106)
Compiled on Mon Dec 14 21:11:21 2015
HW: Stackable ICX7250-24-HPOE
==========================================================================
UNIT 1: SL 1:ICX7250-24P POE 24-port Management Module
Serial #:DUI3844L061
License: BASE_SOFT_PACKAGE (LID: fwkINJJnFLG)
P-ASIC 0: type B344, rev 01 ChipBCM56344_A0
==========================================================================
UNIT 1: SL 2:ICX7250-SFP-Plus 8-port 80G Module
==========================================================================
1000 MHz ARM processor ARMv7 88 MHz bus
8192 KB boot flash memory
2048 MB code flash memory
2048 MB DRAM
STACKID 1 system uptime is 42 second(s)
The system :started=warm start reloaded=by"reload"
ICX7250-24P Switch#showlicense
Index Lic Mode Lic Name Lid/Serial No Lic Type Status Lic Period Lic Capacity
Stack unit 1:
1 Node Lock ICX7250-10G-LIC-POD fwkINJJnFLG Normal Active Unlimited 2
ICX7250-24PSwitch#show module
Module StatusPorts Starting MAC
U1:M1 ICX7250-24P POE 24-port ManagementModule OK 24 609c.9f03.af0c
U1:M2 ICX7250-SFP-Plus 8-port 80G Module OK 8 609c.9f03.af25
ICX7250-24PSwitch#
-
MPN:7250-24P
to request a price please fill out the form below...
