Cisco 1700 Series Modular Access Router 64MB DRAM 32MB Memory
P/N CISCO1721
In good working condition
Included:
- 1 x Cisco 1700 Series Modular Access Router 64MB DRAM 32MB Memory - P/N CISCO1721
More Info:
It has a 64MB DRAM which can be expanded up to a maximum of 128MB. It has a plastic chassis and a flash memory of 32MB. The Cisco 1721 modular access router has one console and auxillary port each..
The Cisco 1721 is a modular router optimized for data-access applications, providing businesses with the most complete functionality and flexibility to deliver secure Internet and Intranet access. The router offers a wide array of WAN access options, high-performance routing, Quality of Service, inter-virtual LAN routing, and VPN access with firewall options. Powered by Cisco IOS, the Cisco 1721 offers high reliability and flexibility of interchangeable WAN interface cards, comprehensive security that includes hardware-assisted VPN encryption and a stateful inspection firewall, and business-class DSL with enhanced quality of service to ensure high-performance levels are guaranteed.
Key Benefits:
- Cost-effective modular device optimized for data-access applications
- Offers a wide array of WAN access options, high-performance routing, VLAN routing, and VPN access with firewall options
- Offers business-class DSL through ADSL and G.SHDSL technologies with enhanced QoS
| General |
| Device Type |
Router |
| Form Factor |
External - 1U |
| Width |
34.3 cm |
| Depth |
27.4 cm |
| Height |
4.4 cm |
| Memory |
| RAM |
128 MB (installed) / 384 MB (max) |
| Flash Memory |
32 MB (installed) / 128 MB (max) |
| Networking |
| Connectivity Technology |
Wired |
| Integrated Switch |
8-port switch |
| Data Link Protocol |
Ethernet, Fast Ethernet |
| Switching Protocol |
Ethernet |
| Network / Transport Protocol |
IPSec |
| Routing Protocol |
OSPF, RIP-1, RIP-2, BGP, EIGRP |
| Remote Management Protocol |
SNMP, HTTP |
| Features |
Firewall protection, hardware encryption, VPN support, load balancing, VLAN support, Stateful Packet Inspection (SPI), manageable, Intrusion Prevention System (IPS), URL filtering |
| Compliant Standards |
IEEE 802.1Q |
| Communications |
| Type |
DSL modem |
| Digital Signaling Protocol |
SHDSL |
| Protocols & Specifications |
ITU G.991.2 (G.shdsl) |
| Expansion / Connectivity |
| Expansion Slots Total (Free) |
CompactFlash Card ¦ Memory |
| Interfaces |
8 x network - Ethernet 10Base-T/100Base-TX - RJ-45 ¦ 1 x modem - SHDSL ( WAN ) ¦ 1 x network - Ethernet 10Base-T/100Base-TX - RJ-45 ( WAN ) ¦ 1 x modem - ISDN BRI ST ¦ 1 x management - auxiliary ¦ 1 x management - console |
| Miscellaneous |
| Rack Mounting Kit |
Optional |
| Encryption Algorithm |
DES, Triple DES, AES |
| Authentication Method |
Secure Shell v.2 (SSH2) |
| Compliant Standards |
EN 60950, EN 61000-3-2, IEC 60950, EN 61000-3-3, EN55022 Class A, UL 60950, CSA 22.2 No. 60950, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-6-2, EN 61000-4-11 |
| Power |
| Power Device |
Power supply - internal |
| Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
| Power Provided |
50 Watt |
| Software / System Requirements |
| OS Provided |
Cisco IOS Advanced IP services |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
10 - 85% |
