Router - CISCO2911/K9
Card - HWIC-1FE
In Good Condition And Full Working Order
NO RACK MOUNT EARS INCLUDED
Included:
- 1 x Cisco 2911 CISCO2911/K9 Integrated Services Router 2U 3x Gigabit Ethernet Ports
- 1 x HWIC-1FE Cisco HWIC-1FE 1 Port Fast Ethernet High Speed WIC Interface Card / Adapter
Cisco 2900 series offer unparalleled total cost of ownership savings and network agility through the intelligent integration of market leading security, unified communications, wireless, and application services.The Cisco 2900 series ISRs offer embedded hardware encryption acceleration, voice- and video-capable digital signal processor (DSP) slots, optional firewall, intrusion prevention, call processing, voicemail, and application services. In addition, the platforms support the industries widest range of wired and wireless connectivity options such as T1/E1, xDSL, copper and fiber GE.
| Cisco 2911 Router Details | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | CISCO2911/K9 |
| Product Type | Router |
| Form Factor | External - modular - 2U |
| Dimensions (WxDxH) | 43.8 cm x 30.5 cm x 8.9 cm |
| Weight | 8.2 kg |
| DRAM Memory | 512 MB (installed) / 2 GB (max) |
| Flash Memory | 256 MB (installed) / 8 GB (max) |
| Routing Protocol | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | SNMP, RMON |
| Features | Cisco IOS IP Base , firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED) |
| Compliant Standards | IEEE 802.1Q, IEEE 802.3af, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag |
| Power | AC 120/230 V ( 50/60 Hz ) |
M/N: Cisco 2911 S/N: FGL154010RB
Username: N/A Password: N/A
System Bootstrap,Version 15.0(1r)M12, RELEASE SOFTWARE (fc1)
TechnicalSupport: http://www.cisco.com/techsupport
Copyright (c)2011 by cisco Systems, Inc.
Total memory size= 512 MB - On-board = 512 MB, DIMM0 = 0 MB
CISCO2911/K9platform with 524288 Kbytes of main memory
Main memory isconfigured to 72/-1(On-board/DIMM0) bit mode with ECC enabled
Readonly ROMMON initialized
program loadcomplete, entry point: 0x80803000, size: 0x1b340
program loadcomplete, entry point: 0x80803000, size: 0x1b340
IOS Image LoadTest
___________________
Digitally SignedRelease Software
program loadcomplete, entry point: 0x81000000, size: 0x475223c
Selfdecompressing the image :##############################################################################################################################################################################################################################################################################################################################################################################################################################################################[OK]
Smart Init isenabled
smart init issizing iomem
TYPE MEMORY_REQ
HWIC Slot 0 0x00200000
Onboard devices &
buffer pools 0x022F6000
-----------------------------------------------
TOTAL: 0x024F6000
Rounded IOMEM upto: 40Mb.
Using 7 percentiomem. [40Mb/512Mb]
Restricted Rights Legend
Use, duplication,or disclosure by the Government is
subject torestrictions as set forth in subparagraph
(c) of theCommercial Computer Software - Restricted
Rights clause atFAR sec. 52.227-19 and subparagraph
(c) (1) (ii) ofthe Rights in Technical Data and Computer
Software clauseat DFARS sec. 252.227-7013.
cisco Systems, Inc.
170 West Tasman Drive
San Jose, California 95134-1706
Cisco IOSSoftware, C2900 Software (C2900-UNIVERSALK9-M), Version 15.1(4)M1, RELEASESOFTWARE (fc1)
TechnicalSupport: http://www.cisco.com/techsupport
Copyright (c)1986-2011 by Cisco Systems, Inc.
Compiled Tue14-Jun-11 19:25 by prod_rel_team
This productcontains cryptographic features and is subject to United
States and localcountry laws governing import, export, transfer and
use. Delivery ofCisco cryptographic products does not imply
third-partyauthority to import, export, distribute or use encryption.
Importers,exporters, distributors and users are responsible for
compliance withU.S. and local country laws. By using this product you
agree to complywith applicable laws and regulations. If you are unable
to comply withU.S. and local laws, return this product immediately.
A summary of U.S.laws governing Cisco cryptographic products may be found at:
http://www.cisco.com/wwl/export/crypto/tool/stqrg.html
If you requirefurther assistance please contact us by sending email to
export@cisco.com.
CiscoCISCO2911/K9 (revision 1.0) with 483328K/40960K bytes of memory.
Processor boardID FGL154010RB
1 FastEthernetinterface
3 GigabitEthernet interfaces
1 terminal line
DRAMconfiguration is 64 bits wide with parity enabled.
255K bytes ofnon-volatile configuration memory.
255744K bytes ofATA System CompactFlash 0 (Read/Write)
--- System Configuration Dialog ---
Would you like toenter the initial configuration dialog? [yes/no]: n
Press RETURN toget started!
Jan 2 12:00:04.355:%IOS_LICENSE_IMAGE_APPLICATION-6-LICENSE_LEVEL: Module name = c2900 Next rebootlevel = ipbasek9 and License = ipbasek9
Jan 2 12:00:04.547:%IOS_LICENSE_IMAGE_APPLICATION-6-LICENSE_LEVEL: Module name = c2900 Next rebootlevel = datak9 and License = datak9
Feb 2813:16:37.867: %ESWMRVL_FLTMG-5-NOTICE: Notice: FPGA Rev 0x27
Feb 2813:16:41.835: %LINK-3-UPDOWN: Interface GigabitEthernet0/0, changed state todown
Feb 2813:16:41.835: %LINK-3-UPDOWN: Interface GigabitEthernet0/1, changed state todown
Feb 2813:16:41.835: %LINK-3-UPDOWN: Interface GigabitEthernet0/2, changed state todown
Feb 2813:16:43.079: %LINEPROTO-5-UPDOWN: Line protocol on InterfaceGigabitEthernet0/0, changed state to down
Feb 28 13:16:43.079:%LINEPROTO-5-UPDOWN: Line protocol on Interface GigabitEthernet0/1, changedstate to down
Feb 2813:16:43.079: %LINEPROTO-5-UPDOWN: Line protocol on InterfaceGigabitEthernet0/2, changed state to down
Feb 2813:16:43.079: %LINEPROTO-5-UPDOWN: Line protocol on InterfaceFastEthernet0/0/0, changed state to down
Feb 2813:17:33.815: %IP-5-WEBINST_KILL: Terminating DNS process
Feb 2813:17:35.167: %LINK-5-CHANGED: Interface Embedded-Service-Engine0/0, changedstate to administratively down
Feb 28 13:17:35.167:%LINK-5-CHANGED: Interface GigabitEthernet0/0, changed state toadministratively down
Feb 2813:17:35.167: %LINK-5-CHANGED: Interface GigabitEthernet0/1, changed state toadministratively down
Feb 2813:17:35.167: %LINK-5-CHANGED: Interface GigabitEthernet0/2, changed state toadministratively down
Feb 2813:17:35.167: %LINK-5-CHANGED: Interface FastEthernet0/0/0, changed state toadministratively down
Feb 2813:17:36.167: %LINEPROTO-5-UPDOWN: Line protocol on InterfaceEmbedded-Service-Engine0/0, changed state to down
Feb 2813:17:42.363: %SYS-5-RESTART: System restarted --
Cisco IOSSoftware, C2900 Software (C2900-UNIVERSALK9-M), Version 15.1(4)M1, RELEASESOFTWARE (fc1)
TechnicalSupport: http://www.cisco.com/techsupport
Copyright (c)1986-2011 by Cisco Systems, Inc.
Compiled Tue14-Jun-11 19:25 by prod_rel_team
Feb 2813:17:42.363: %SNMP-5-COLDSTART: SNMP agent on host Router is undergoing a coldstart
Router>en
Router#showlicense
Index 1 Feature:ipbasek9
Period left: Life time
License Type: Permanent
License State: Active, In Use
License Count: Non-Counted
License Priority: Medium
Index 2 Feature:securityk9
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA notaccepted
License Count: Non-Counted
License Priority: None
Index 3 Feature:uck9
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA notaccepted
License Count: Non-Counted
License Priority: None
Index 4 Feature:datak9
Period left: Life time
License Type: Permanent
License State: Active, In Use
License Count: Non-Counted
License Priority: Medium
Index 5 Feature:gatekeeper
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA notaccepted
License Count: Non-Counted
License Priority: None
Index 6 Feature:SSL_VPN
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA not accepted
License Count: 0/0 (In-use/Violation)
License Priority: None
Index 7 Feature:ios-ips-update
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA notaccepted
License Count: Non-Counted
License Priority: None
Index 8 Feature:SNASw
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA notaccepted
License Count: Non-Counted
License Priority: None
Index 9 Feature:hseck9
Index 10 Feature:cme-srst
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA notaccepted
License Count: 0/0 (In-use/Violation)
License Priority: None
Index 11 Feature:WAAS_Express
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA notaccepted
License Count: Non-Counted
License Priority: None
Index 12 Feature:UCVideo
Period left: Not Activated
Period Used: 0 minute 0 second
License Type: EvalRightToUse
License State: Not in Use, EULA notaccepted
License Count: Non-Counted
License Priority: None
Router#showinventory
NAME:"CISCO2911/K9 chassis", DESCR: "CISCO2911/K9 chassis"
PID:CISCO2911/K9 , VID: V04 , SN:FGL154010RB
NAME:"One-Port Fast Ethernet High Speed WAN Interface Card on Slot 0 SubSlot0", DESCR: "One-Port Fast Ethernet High Speed WAN InterfaceCard"
PID:HWIC-1FE , VID: V02 , SN:FOC16142KH6
NAME: "C2911AC Power Supply", DESCR: "C2911 AC Power Supply"
PID:PWR-2911-AC , VID: V03 , SN:DCA1522R0AQ
Router#sh ver
Cisco IOSSoftware, C2900 Software (C2900-UNIVERSALK9-M), Version 15.1(4)M1, RELEASESOFTWARE (fc1)
TechnicalSupport: http://www.cisco.com/techsupport
Copyright (c)1986-2011 by Cisco Systems, Inc.
Compiled Tue14-Jun-11 19:25 by prod_rel_team
ROM: SystemBootstrap, Version 15.0(1r)M12, RELEASE SOFTWARE (fc1)
Router uptime is2 minutes
System returnedto ROM by power-on
System restartedat 13:16:18 UTC Thu Feb 28 2019
System image fileis "flash0:c2900-universalk9-mz.SPA.151-4.M1.bin"
Last reload type:Normal Reload
This productcontains cryptographic features and is subject to United
States and localcountry laws governing import, export, transfer and
use. Delivery ofCisco cryptographic products does not imply
third-partyauthority to import, export, distribute or use encryption.
Importers,exporters, distributors and users are responsible for
compliance withU.S. and local country laws. By using this product you
agree to complywith applicable laws and regulations. If you are unable
to comply withU.S. and local laws, return this product immediately.
A summary of U.S.laws governing Cisco cryptographic products may be found at:
http://www.cisco.com/wwl/export/crypto/tool/stqrg.html
If you requirefurther assistance please contact us by sending email to
export@cisco.com.
CiscoCISCO2911/K9 (revision 1.0) with 483328K/40960K bytes of memory.
Processor boardID FGL154010RB
1 FastEthernetinterface
3 GigabitEthernet interfaces
1 terminal line
DRAMconfiguration is 64 bits wide with parity enabled.
255K bytes ofnon-volatile configuration memory.
255744K bytes ofATA System CompactFlash 0 (Read/Write)
License Info:
License UDI:
-------------------------------------------------
Device# PID SN
-------------------------------------------------
*0 CISCO2911/K9 FGL154010RB
TechnologyPackage License Information for Module:'c2900'
-----------------------------------------------------------------
Technology Technology-package Technology-package
Current Type Next reboot
------------------------------------------------------------------
ipbase ipbasek9 Permanent ipbasek9
security None None None
uc None None None
data datak9 Permanent datak9
Configurationregister is 0x2102
Router#
-
MPN:CISCO2911/K9
