Western Digital WD400BB-23JHA1 WD Caviar 40GB 7200RPM 2MB 3.5" ATA-100 HDD
AJ 205022 NWP
Model Number: WD400BB-23JHA1
In good condition and in full working order
Includes
- 1 x Western Digital WD400BB-23JHA1 WD Caviar 40GB 7200RPM 2MB 3.5" ATA-100 HDD
More Info:
GENERAL
Capacity 40 GB
Bytes per Sector 512
Interface ATA-100
Buffer Size 2 MB
Weight 1.32 lbs
Manufacturer Western Digital Corp.
MISCELLANEOUS
Mounting Kit included
PERFORMANCE
Internal Data Rate 50 MBps
Seek Time 8.9 ms (average) / 21 ms (max)
Drive Transfer Rate 100 MBps (external)
Average Latency 4.2 ms
Spindle Speed 7200 rpm
Track-to-Track Seek Time 2 ms
EXPANSION & CONNECTIVITY
Connections 1 x storage - ATA-100 - 40 pin IDC
HARD DRIVE
Form Factor 3.5" x 1/3H
Interface Type ATA-100
Spindle Speed 7200 rpm
Hard Drive Type internal hard drive
Form Factor (Short) 3.5"
Form Factor (metric) 8.9 cm x 1/3H
Form Factor (Short) (metric) 8.9 cm
Storage Interface ATA-100
Interface ATA-100
Average Seek Time 8.9 ms
Max Seek Time 21 ms
Track-to-Track Seek Time 2 ms
Average Latency 4.2 ms
Data Transfer Rate 100 MBps
Internal Data Rate 50 MBps
Buffer Size 2 MB
Bytes per Sector 512 Hz
Non-Recoverable Errors 1 per 10^14
Start / Stop Cycles 40000
SOFTWARE & SYSTEM REQUIREMENTS
Software Included Drivers & Utilities
ENVIRONMENTAL PARAMETERS
Max Altitude Operating 9840 ft
Min Operating Temperature 41 °F
Max Operating Temperature 131 °F
Humidity Range Operating 5 - 85%
Sound Emission 35 dBA
Sound Emission 35 dBA
STORAGE HARD DRIVE
Compliant Standards S.M.A.R.T.
HEADER
Brand WD
Product Line WD Caviar
Model WD400BB
Packaged Quantity 1
Compatibility PC
INTERFACE REQUIRED
Connector Type 40 pin IDC
Gender female
Connector Qty 1
Total Qty 1
DIMENSIONS & WEIGHT
Width 4 in
Depth 5.8 in
Height 1 in
Weight 1.32 lbs
BAY REQUIRED
Type internal
Form Factor 3.5" x 1/3H
Form Factor (metric) 8.9 cm x 1/3H
Total Qty 1
RELIABILITY
Non-Recoverable Errors 1 per 10^14
Start / Stop Cycles 40,000
GENERAL
Manufacturer Western Digital Corp.
