Cisco 2901 CISCO2901-V/K9 ISR G2 Voice Bundle Router + 1x
VWIC3-2MFT-T1/E1 Card
Model: CISCO2901-V/K9
P/N: VIC3-4FXS/DID
P/N: VWIC3-2MFT-T1/E1
In Good Condition
In Full Working Order
Tested
Supplied With 2 Years Warranty
Not Supplied With Rackmount Ears
Included
- 1 x Cisco 2901 CISCO2901-V/K9 ISR G2 Voice Bundle Router
- 1 x Cisco VIC3-4FXS/DID 4-Port Analog FXS DID Voice Fax Interface Card Module
- 1 x Cisco VWIC3-2MFT-T1/E1 - Multiflex Trunk Voice & WAN Expansion Card
Overview
Cisco 2900 Series Integrated Services Routers build on 25 years of Cisco innovation and product leadership. The new platforms are architected to enable the next phase of branch-office evolution, providing rich media collaboration and virtualization to the branch while maximizing operational cost savings The Integrated Services Routers Generation 2 platforms are future-enabled with multi-core CPUs, support for high capacity DSPs (Digital Signal Processors) for future enhanced video capabilities, high powered service modules with improved availability, Gigabit Ethernet switching with enhanced POE, and new energy monitoring and control capabilities while enhancing overall system performance. Additionally, a new Cisco IOS Software Universal image and Services Ready Engine module enable you to decouple the deployment of hardware and software, providing a flexible technology foundation which can quickly adapt to evolving network requirements. Overall, the Cisco 2900 Series offer unparalleled total cost of ownership savings and network agility through the intelligent integration of market leading security, unified communications, wireless, and application services.
The Cisco 2901 Integrated Services Router (ISR) delivers highly secure data, voice, video, and application services for small offices. Key features include:
- 2 integrated 10/100/1000 Ethernet ports
- 4 enhanced high-speed WAN interface card slots
- 2 onboard digital signal processor (DSP) slots
- 1 onboard Internal Service Module for application services
- Fully integrated power distribution to modules supporting 802.3af Power over Ethernet (PoE) and Cisco Enhanced PoE
Security
- Embedded hardware-accelerated VPN encryption for secure collaborative VPN communications
- Integrated threat control using Cisco IOS Firewall, Cisco IOS Zone-Based Firewall, Cisco IOS IPS, and Cisco IOS Content Filtering
- Identity management that uses authentication, authorization, and accounting (AAA) and public key infrastructure
Voice
- High-density-packet voice DSP module, optimized for voice and video
- Standards-certified VoiceXML browser services
- Cisco Unified Border Element capabilities
- Cisco Unity Express voicemail support
- Support for Cisco Communications Manager Express and Survivable Remote Site Telephony
Specification
- Manufacturer: Cisco Systems, Inc
- Product Type: Router
- Form Factor: External - modular - 1U
- Dimensions (WxDxH): 43.9 cm x 43.8 cm x 4.5 cm
- Weight: 6.1 kg
- DRAM Memory: 512 MB (installed) / 2 GB (max)
- Flash Memory: 256 MB (installed) / 8 GB (max)
- Routing Protocol: OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing
- Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Protocol: SNMP, RMON
- Digital Ports Qty: 16
- Features: Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED)
- Compliant Standards: IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag
- Power: AC 120/230 V ( 50/60 Hz )
VAT IS NOT PAYABLE BY PURCHASERS OUTSIDE OF THE UK
TH 251975
specifications
-
MPN:CISCO2901-V/K9
