Cisco Nexus C9504 N9K-C9504 4-Slot Switch Chassis 2x N9K-SUP-A 2x N9K-SC-A

Cisco Nexus Operating System (NX-OS) Software
TAC support: http://www.cisco.com/tac
Copyright (C) 2002-2021, Cisco and/or its affiliates.
All rights reserved.
The copyrights to certain works contained in this software are
owned by other third parties and used and distributed under their own
licenses, such as open source. This software is provided "as is," and unless
otherwise stated, there is no warranty, express or implied, including but not
limited to warranties of merchantability and fitness for a particular purpose.
Certain components of this software are licensed under
the GNU General Public License (GPL) version 2.0 or
GNU General Public License (GPL) version 3.0 or the GNU
Lesser General Public License (LGPL) Version 2.1 or
Lesser General Public License (LGPL) Version 2.0.
A copy of each such license is available at
http://www.opensource.org/licenses/gpl-2.0.php and
http://opensource.org/licenses/gpl-3.0.html and
http://www.opensource.org/licenses/lgpl-2.1.php and
http://www.gnu.org/licenses/old-licenses/library.txt.
switch# show version
Cisco Nexus Operating System (NX-OS) Software
TAC support: http://www.cisco.com/tac
Copyright (C) 2002-2021, Cisco and/or its affiliates.
All rights reserved.
The copyrights to certain works contained in this software are
owned by other third parties and used and distributed under their own
licenses, such as open source. This software is provided "as is," and unless
otherwise stated, there is no warranty, express or implied, including but not
limited to warranties of merchantability and fitness for a particular purpose.
Certain components of this software are licensed under
the GNU General Public License (GPL) version 2.0 or
GNU General Public License (GPL) version 3.0 or the GNU
Lesser General Public License (LGPL) Version 2.1 or
Lesser General Public License (LGPL) Version 2.0.
A copy of each such license is available at
http://www.opensource.org/licenses/gpl-2.0.php and
http://opensource.org/licenses/gpl-3.0.html and
http://www.opensource.org/licenses/lgpl-2.1.php and
http://www.gnu.org/licenses/old-licenses/library.txt.

Software
BIOS: version 08.39
NXOS: version 10.1(2)
BIOS compile time: 04/04/2021
NXOS image file is: bootflash:///nxos.10.1.2.bin
NXOS compile time: 5/13/2021 17:00:00 [05/14/2021 02:21:06]

Hardware
cisco Nexus9000 C9504 (4 Slot) Chassis ("Supervisor Module")
Intel(R) Xeon(R) CPU E5-2403 v2 @ 1.80GHz with 16395440 kB of memory.
Processor Board ID FOC21251BTN
Device name: switch
bootflash: 21693714 kB

Kernel uptime is 0 day(s), 0 hour(s), 5 minute(s), 46 second(s)

Last reset at 753667 usecs after Fri Dec 6 11:37:52 2024
Reason: Reset Requested by CLI command reload
System version: 10.1(2)
Service:

plugin
Core Plugin, Ethernet Plugin

Active Package(s):

switch# show inventory
NAME: "Chassis", DESCR: "Nexus9000 C9504 (4 Slot) Chassis"
PID: N9K-C9504 , VID: V01 , SN: FOX2120P53J

NAME: "Slot 22", DESCR: "4-slot Fabric Module"
PID: N9K-C9504-FM-E , VID: V02 , SN: FOC21112MJX

NAME: "Slot 23", DESCR: "4-slot Fabric Module"
PID: N9K-C9504-FM-E , VID: V02 , SN: FOC21096DMS

NAME: "Slot 24", DESCR: "4-slot Fabric Module"
PID: N9K-C9504-FM-E , VID: V02 , SN: FOC21112MKJ

NAME: "Slot 27", DESCR: "Supervisor Module"
PID: N9K-SUP-A , VID: V04 , SN: FOC21251BTN

NAME: "Slot 28", DESCR: "Supervisor Module"
PID: N9K-SUP-A , VID: V04 , SN: FOC21251C05

NAME: "Slot 29", DESCR: "System Controller"
PID: N9K-SC-A , VID: V01 , SN: FOC21186MMR

NAME: "Slot 30", DESCR: "System Controller"
PID: N9K-SC-A , VID: V01 , SN: FOC21186MRG

NAME: "Power Supply 2", DESCR: "Nexus9000 C9504 (4 Slot) Chassis Power Supply"
PID: N9K-PAC-3000W-B , VID: V03 , SN: ART2116F9J3

NAME: "Fan 1", DESCR: "Nexus9000 C9504 (4 Slot) Chassis Fan Module"
PID: N9K-C9504-FAN , VID: V01 , SN: FOX2123P7JH

NAME: "Fan 2", DESCR: "Nexus9000 C9504 (4 Slot) Chassis Fan Module"
PID: N9K-C9504-FAN , VID: V01 , SN: FOX2123P7JE

NAME: "Fan 3", DESCR: "Nexus9000 C9504 (4 Slot) Chassis Fan Module"
PID: N9K-C9504-FAN , VID: V01 , SN: FOX2123P157

switch# show license usage
Feature Ins Lic Status Expiry Date Comments
Count
-------------------------------------------------------------------------------
ACI-STRG No - Unused -
ACI-AD-GF No - Unused -
ACI-AD-XF No - Unused -
ACI-ES-GF No - Unused -
ACI-ES-XF No - Unused -
ACI-AD-XF2 No - Unused -
ACI-ES-XF2 No - Unused -
ACI-SEC-GF No - Unused -
ACI-SEC-XF No - Unused -
ACI-SEC-XM No 0 Unused -
N9K_LIC_1G No - Unused -
VPN_FABRIC No - Unused -
ACI-STRG-GF No - Unused -
ACI-STRG-XF No - Unused -
NXOS_OE_PKG No - Unused -
FCOE_NPV_PKG No - Unused -
SECURITY_PKG No 0 Unused -
ACI-PREMIER-GF No - Unused -
ACI-PREMIER-XF No - Unused -
N9K_UPG_EX_10G No - Unused -
ACI-PREMIER-XF2 No - Unused -
NXOS-PREMIER-M4 No - Unused -
TP_SERVICES_PKG No - Unused -
NXOS-PREMIER-M816 No - Unused -
NXOS_ADVANTAGE_GF No - Unused -
NXOS_ADVANTAGE_M4 No - Unused -
NXOS_ADVANTAGE_XF No - Unused -
NXOS_ESSENTIALS_GF No - Unused -
NXOS_ESSENTIALS_M4 No - Unused -
NXOS_ESSENTIALS_XF No - Unused -
NXOS_ESSENTIALS_XM No - Unused -
SAN_ENTERPRISE_PKG No - Unused -
PORT_ACTIVATION_PKG No 0 Unused -
NETWORK_SERVICES_PKG No - Unused -
NXOS_ADVANTAGE_M8-16 No - Unused -
NXOS_ESSENTIALS_M8-16 No - Unused -
FC_PORT_ACTIVATION_PKG No 0 Unused -
LAN_ENTERPRISE_SERVICES_PKG Yes - Unused never -
-------------------------------------------------------------------------------

switch# show environment
Fan:
---------------------------------------------------------------------------
Fan Model Hw Direction Status
---------------------------------------------------------------------------
Fan1(sys_fan1) N9K-C9504-FAN 1.0 front-to-back Ok
Fan2(sys_fan2) N9K-C9504-FAN 1.0 front-to-back Ok
Fan3(sys_fan3) N9K-C9504-FAN 1.0 front-to-back Ok
Fan_in_PS1 -- front-to-back None
Fan_in_PS2 -- front-to-back Ok
Fan_in_PS3 -- front-to-back None
Fan_in_PS4 -- front-to-back None
Fan Zone Speed: Zone 1: 0x0
Fan Air Filter : NotSupported


Power Supply:
Voltage: 12 Volts
Power Actual Actual Total
Supply Model Output Input Capacity Status
(Watts ) (Watts ) (Watts )
------- ---------- --------------- ------ ---------- --------------------
1 ------------ 0 W 0 W 0 W Absent
2 N9K-PAC-3000W-B 545 W 591 W 3000 W Ok
3 ------------ 0 W 0 W 0 W Absent
4 ------------ 0 W 0 W 0 W Absent


Actual Power
Module Model Draw Allocated Status
(Watts ) (Watts )
------- ------------------- ----------- ----------- --------------
Xb21 xbar N/A 0.00 W Absent
Xb22 N9K-C9504-FM-E 111.00 W 312.00 W Powered-Up
Xb23 N9K-C9504-FM-E 95.00 W 312.00 W Powered-Up
Xb24 N9K-C9504-FM-E 88.00 W 312.00 W Powered-Up
Xb25 xbar N/A 0.00 W Absent
27 N9K-SUP-A 56.00 W 90.00 W Powered-Up
28 N9K-SUP-A 54.00 W 90.00 W Powered-Up
29 N9K-SC-A 14.00 W 25.20 W Powered-Up
30 N9K-SC-A 14.00 W 25.20 W Powered-Up
fan1 N9K-C9504-FAN 28.00 W 129.00 W Powered-Up
fan2 N9K-C9504-FAN 26.00 W 129.00 W Powered-Up
fan3 N9K-C9504-FAN 31.00 W 129.00 W Powered-Up

N/A - Per module power not available


Power Usage Summary:
--------------------
Power Supply redundancy mode (configured) PS-Redundant
Power Supply redundancy mode (operational) Non-Redundant

Total Power Capacity (based on configured mode) 3000.00 W
Total Grid-A (first half of PS slots) Power Capacity 3000.00 W
Total Grid-B (second half of PS slots) Power Capacity 0.00 W
Total Power of all Inputs (cumulative) 3000.00 W
Total Power Output (actual draw) 545.00 W
Total Power Input (actual draw) 591.00 W
Total Power Allocated (budget) 1868.00 W
Total Power Available for additional modules 1132.00 W



Temperature:
--------------------------------------------------------------------
Module Sensor MajorThresh MinorThres CurTemp Status
(Celsius) (Celsius) (Celsius)
--------------------------------------------------------------------
22 CPU 85 75 17 Ok
22 LAC 105 95 42 Ok
22 VRM 110 100 38 Ok
23 CPU 85 75 19 Ok
23 LAC 105 95 32 Ok
23 VRM 110 100 42 Ok
24 CPU 85 75 17 Ok
24 LAC 105 95 33 Ok
24 VRM 110 100 37 Ok
26 CPU 85 75 16 Ok
26 LAC 105 95 35 Ok
26 VRM 110 100 36 Ok
27 OUTLET 75 55 25 Ok
27 INLET 60 42 17 Ok
27 CPU 90 80 25 Ok
28 OUTLET 75 55 24 Ok
28 INLET 60 42 18 Ok
28 CPU 90 80 29 Ok
29 CPU 105 95 33 Ok
30 CPU 105 95 37 Ok
