Dell EMC PowerSwitch N3248TE-ON 48x 1G RJ45 4x SFP+ 2x QSFP28 RA Switch OS10

Condition : Refurbished – tested and working grade A refurbished part

Dell EMC PowerSwitch N3248TE-ON 48x 1G RJ45 4x SFP+ 2x QSFP28 RA Switch OS10 – Refurbished

Overview:
The Dell EMC PowerSwitch N3248TE-ON is a high-performance, energy-efficient 1GbE Layer 3 distribution switch featuring integrated 10GbE SFP+ and 100GbE QSFP28 ports. Designed with a non-blocking architecture, it delivers wire-speed performance to manage heavy traffic loads seamlessly. This 1RU switch supports rear-to-front airflow and comes pre-installed with OS10 Enterprise software.

Key Features:
- 48 x 1GbE RJ45 ports for reliable copper connectivity
- 4 x 10GbE SFP+ ports and 2 x 100GbE QSFP28 ports for high-speed uplinks
- Dual hot-swappable 80PLUS Platinum certified power supplies for power efficiency and high availability
- Variable speed fans to reduce cooling and power consumption
- Energy-Efficient Ethernet technology reduces power usage on inactive and idle links
- Dell Fresh Air compliance for operation in environments up to 45°C (113°F)
- Multiple management ports including USB, MicroUSB console, and RJ45 console for versatile configuration options
- Supports Layer 2 and Layer 3 switching and routing at line rate

Hardware Specifications:
- Dimensions: 1.71 in (H) x 17.09 in (W) x 15.75 in (D) (additional 1.18 in for PSU/fan tray handle)
- Weight: Approximately 6.99 kg (15.4 lbs) with one PSU installed
- Power supply: 550W 80PLUS Platinum certified, optional second PSU for redundancy
- Cooling: Redundant variable speed fans with normal or reverse airflow options
- Switching capacity: 576 Gbps full-duplex
- Forwarding rate: 800 Mpps
- Memory: 4GB CPU memory, 32GB SSD, 8MB packet buffer

Environmental:
- Operating temperature range: 0° to 45°C (32° to 113°F)
- Operating humidity: Up to 95% relative humidity
- Power efficiency: 88% or better in all operating modes

Included Items:
- Dell EMC PowerSwitch N3248TE-ON switch
- Power supply unit (PSU to IO)
- Three fan modules (
