HPE FlexFabric 5945 32x 100G QSFP28 2x 1G SFP B2F Managed Network Switch JQ077A

Condition : Refurbished – tested and working grade A refurbished part

HPE FlexFabric 5945 Managed Network Switch JQ077A Specifications: - Ports: 32 x 100G QSFP28 (breakout to 4 x 25GbE or 4 x 10GbE per port via splitter), 2 x 1G SFP - Out-of-Band Management Ports: 1 x RJ45 Copper, 1 x SFP Fibre - Console Ports: 1 x RJ45, 1 x Mini-USB - USB Host Port: 1 x USB Type-A - Switching Capacity: 6.4 Tbps full-duplex - Architecture: Cut-Through, Non-Blocking, Wire-Speed - Latency: <1 μs (100GbE) - MAC Address Table: 288,000 entries - VLANs: Supports up to 4,096 - Jumbo Frames: Up to 9,416 bytes - Link Aggregation: Supports up to 256 LAG groups (LACP) Layer 2/3 Features: - IPv4 & IPv6 Routing: Static, RIP, OSPF, BGP, IS-IS, ECMP, Policy-Based Routing, VRRP - Spanning Tree Protocols: STP, RSTP, MSTP - Multicast: PIM-DM, PIM-SM, IGMP Snooping Management & Security: - SNMP v1/v2c/v3, sFlow, LLDP, Port Mirroring - Time Synchronisation: PTP (IEEE 1588v2), NTP - CLI Access: Telnet, SSH - Security: Role-Based Access Control (RBAC), Configuration Rollback, MACsec 256-bit Encryption (with supported modules) Suitable for high-performance data centre and enterprise networking deployments.
