Mellanox SX6512 216-Port FDR/FDR10/QDR Capable 12-Slot Switch Chassis MSX6512-NR

Condition : Refurbished – tested and working grade A refurbished part

Mellanox SX6512 12-Slot Switch Chassis delivering up to 216 ports supporting FDR, FDR10, and QDR InfiniBand protocols. Provides 24.2Tb/s of non-blocking bandwidth with sub-microsecond port latency in a 9U modular chassis. Features hot-swappable leaf, spine, management modules, power supplies, and fan units for high availability. Includes 4x 1670W power supplies and 4x fan modules. Designed for scalable, high-performance data centre fabrics with support for static and adaptive routing, congestion control, and software-defined networking (SDN) capabilities. Onboard subnet manager supports up to 648 nodes. MLNX-OS software offers comprehensive chassis management and embedded diagnostics. Compatible with Mellanox Unified Fabric Manager (UFM) for enhanced fabric provisioning and monitoring. Specifications: compliant with IBTA 1.2 and 1.3, MTU range 256 to 4K bytes, 4x 48K entry linear forwarding table, passive copper and active fibre cables supported, front-to-rear airflow, input voltage 90-264VAC, frequency 47-63Hz single phase AC.
