SUPERMICRO AOC-9300-16E LSI 9300-16E SAS 12G/s 16-Port Host Bus Adapter HBA

Condition : Refurbished – tested and working grade A refurbished part

SUPERMICRO AOC-9300-16E LSI 9300-16E SAS Host Bus Adapter (HBA)

Features:
- 16 ports supporting 12Gb/s SAS 3.0 compliant
- IO Controller: Two LSISAS3008 / Fusion MPT 2.5
- SAS bandwidth: Half duplex (x4 wide bus) at 4800 MB/s
- Port configurations: 16 x1 ports, 4 x4 wide ports, 2 x8 wide ports
- Host bus: x8 lane, PCI Express 3.0 compliant
- PCI data burst transfer rates: Half duplex, x8, PCIe, 8000 MB/s
- Connectors: Four mini-SAS HD external connectors (SFF8644)
- Supports passive and active copper cables
- Operating voltage: +12V ±8%, 3.3V ±9%
- PCI power nominal: 28.6W
- Device support: Up to 1024 non-RAID SATA/SAS devices per controller

Physical Dimensions:
- Size: 4.4” x 6.6”

Environmental:
- Operating temperature: 0°C to 55°C
- Storage temperature: -45°C to 105°C
- Airflow: 200 LFM

Reliability:
- Mean time between failures (MTBF): >1,500,000 hours
